Index MS 22-8

Important data at a glance

8-spindle
Double NCU
Slide unit 1.1: X-axis and Z-axis NC-controlled
Slide unit 1.2: X-axis and Z-axis NC-controlled
Slide unit 2.1: X-axis and Z-axis NC-controlled
Slide unit 2.2: X-axis and Z-axis NC-controlled
Slide unit 3.1: X-axis and Z-axis NC-controlled
Slide unit 3.2: X-axis and Z-axis NC-controlled
Slide unit 4.1: X-axis and Z-axis NC-controlled
Slide unit 4.2: X-axis and Z-axis NC-controlled
Slide unit 5.1: X-axis and Z-axis NC-controlled
Slide unit 5.2: X-axis and Z-axis NC-controlled
Slide unit 6.1: X-axis and Z-axis NC-controlled
Slide unit 6.2: X-axis and Z-axis NC-controlled
Slide unit 7.1: X-axis and Z-axis NC-controlled
Slide unit 7.2: Swivel axis and Z-axis NC-controlled
Slide unit 7.3: X-axis NC-controlled, Z-axis rigid
Slide unit 8.1: Swivel axis and Z-axis NC-controlled
Slide unit 8.2: X-axis and Z-axis NC-controlled
Slide unit 8.3: X-axis NC-controlled, Z-axis rigid
Synchronization device position 7.2
Synchronization device position 8.1
Back side machining possible on positions 7.3 and 8.3 with three rigid and two driven positions
Index loading magazine MBL228/3300 bundle loader
Hinge belt chip conveyor
Röhm three-jaw chuck for synchronous spindle
Workpiece transport belt in spindle position 7
Workpiece transport belt in spindle position 8
Fire extinguishing system
Büchel cooling lubricant extraction system
